Sonoff Basic WiFi Smart Switch [10A]

Sonoff Basic WiFi Smart Switch [10A]
Click image for Gallery
  • Brands ITEAD
  • Product Code:SQ3528
  • Availability: 995
  • $5.99
  • Ex Tax:$5.99
This product has a minimum quantity of 2

Tags: Sonoff Switch, 10A Switch, Single Channel Switch, WiFi Switch, Smart Switch

Sonoff Basic Waterproof WiFi Smart Switch [10A] [IP66] is a remote-controlled wireless switch that can be controlled through the WiFi protocol. This switch is a single channel switch that is specialized for home automation or smart home projects based on IoT system requirements. This smart switch can communicate with other networked devices through the WiFi protocol, to achieve a seamless commanding system over the home equipment. This switch can connect to a variety of WI-Fi boards and application adopted2.4GHz 802.b/g/n with or without the presence of the internet. This switch can transfer data to the cloud platform through the routers or switches, results in achieving this switch from anywhere of the world through the internet by phone or PC.
A specific IP66 case is separately provided and presented for this intelligent switch that can be purchased to protect it against water, rain, steam, dust, etc under the IP class of 66, suitable for bathroom,, kitchen, etc. This smart switch can get a city electricity line with 90 up to 250V AC, 50 to 60Hz frequency and by receiving the wireless command signal, conduct it to a high power load (an electrical device with up to 10A output current and maximum 2200W power) such as light lamps, AC motors, pomps, etc.

Supports WiFi network.
Supports status tracking: device status timely provided to the EWeLink.
Supports remotely turn on or off connected appliance/light.
Supports max 8 enabled scheduled/countdown/loop timers for each device.
Supports numerous WiFi smart switches on one smartphone.
Works with Amazon Echo, Echo Dot, Amazon Tap
Works with Google Home, Google Home Mini, Google Nest
Works with IFTTT
Channel: Single Channel
Input Voltage : 90V ~ 250V AC (50/60Hz)
Maximum Current: 10A
Maximum Power: 2200W
Wireless Frequency: WiFi 2.4GHz
Enclosure Material: Fire-retardant ABS V0
Wireless Standard: 802.11 b/g/n
Security Mechanism: WPA-PSK/WPA2-PSK
Operating Temperature: 0ºC ~ 40ºC
Operating Humidity: 5% ~ 90%RH, Non-condensing
Color: White
Size: 88mm x 38mm x 23mm (LxWxH)

Package Include:
1 x Sonoff Basic WiFi Wireless Switch

Electrical Parameters
Channels Single Channel
Frequency WiFi 2.4GHz
Input Voltage 90V ~ 250V AC
Current 10A (Max)
Power 2200W (Max)
Physical Parameters
Size 88mm x 38mm x 23mm
Color White
Environmental Conditions and Safety
Operating Temprature 0ºC ~ 40ºC
Operating humidity 5% ~ 90%RH
