OV2640 Mini Camera Module with T-Camera ESP32 Wi-Fi Processor.

T-model cameras are compact, feature-rich devices with a sturdy body and lightweight design. The OV2640 Mini Camera Module with T-Camera ESP32 Wi-Fi Processor is an image recognition development board that integrates the ESP32 Wi-Fi module and a 2MP OV2640 camera, enabling image transmission and reception via Wi-Fi. Memory plays a crucial role in camera modules, and this camera features 8MB PSRAM, allowing data transmission through Wi-Fi and debugging via the C port. The module’s output resolution is 800 × 600 pixels, and with software optimization, image sizes can be increased. The OV2640 Camera Module with ESP32 Processor provides versatile functionality for various applications.

Applications of the OV2640 Mini Camera Module

1. Image recognition
2. Facial recognition
3. Wi-Fi image transmission

Specifications of the OV2640 Mini Camera Module

1. Dual-core ESP32 main processor
2. Operating voltage range: 2.7V to 3.6V
3. Typical operating current: approximately 160mA
4. AXP192 power management unit
5. USB power input: 5V / 1A
6. Supports Wi-Fi 802.11 b/g/n and Bluetooth 4.2 (BLE & BR/EDR)
7. 4MB onboard flash memory
8. 8MB PSRAM for extended memory performance
9. Integrated CP2104 UART interface chip
10. Equipped with a 2MP OV2640 image sensor
11. Physical dimensions: 72 × 21 × 21 mm
12. Net weight: 20 grams
