NanoPi NEO Core Shield

NanoPi NEO Core Shield
  • Product Code:SQ6171
  • Availability: In Stock
  • $14.80
  •
  • Ex Tax:$14.80
This product has a minimum quantity of 5
+
-


Tags: NEO Core Shield, NanoPi Shield, NEO Core2 Shield, NanoPI NEO, ARM board

Description:
The NanoPI NEO2 is a newly released super tiny ARM board. It uses Allwinner’s 64-bit H5 quad-core SoC (ARM Cortex-A53).
It featured by internal Hexa-core Mail450 GPU, 512M DDR3 RAM, and UbuntuCore.
NanoPi NEO2 inherits NEO's form factor and includes compatible interfaces and ports with NEO. It also provides high-performance Gbps Ethernet and one USB host port in such a small dimension. These features make it especially suitable for applications that require high and fast data transmission.
The Mini Shield for NanoPi NEO Core/Core2 is a custom SDK carrier board developed for the NanoPi NEO Core and NanoPi NE0 Core2. It features an Ethernet port, Serial Debug Port, audio, USB port, and etc.

Features:
Same form factor as RPi can be well fit into an RPi's case
2 x USB Host
1 x Serial debug port and
1 x Ethernet port
1 x Onboard Microphone
1 x 3.5mm audio jack for audio recording and playing.
2 x 13 Pins GPIO pin-header
1 x Button
1 x M.2 2242 SSD interface
1 x IR receiver interface
1 x Onboard JMS567 USB to SATA IC

Package include:
1 x NanoPi NEO Core / Core2 Shield

Board Parameters
GPIO 2 x 13 Pin
Physical Parameters
Size 85 mm x 56 mm
Weight 76 g
Ports And Jumpers
Debug Port 1 x Serial
USB 2
Audio Input 1 x Onboard Microphone
Audio Output 1 x 3.5mm audio jack
