33m Kapton Tape Adhesive [100ft]

33m Kapton Tape Adhesive [100ft]
  • Product Code:SQ1674
  • Availability: In Stock
  • $1.30
  • Ex Tax:$1.30

Available Options

This product has a minimum quantity of 6

Tags: Polyimide Resistant, Kapton Tape, Kapton Adhesive, 3D Printer Kapton

33m High-Temperature Polyimide Resistant Kapton Tape Adhesive is a roll of green Kapton adhesive tape with a 33 meter (100ft) long, which is made of a high-temperature polyimide heat resistant film with silicone adhesive on its single side. Due to tolerating high temperature and solvent corrosion, it is specialized to PCB soldering and  3D printing for making high-temperature mask conditions. The user can cover the area which should be not heated or soldered, for example, to cover the heat bed of the 3D printer or during wave soldering to cover and protect the PCB gold finger contacts.
This adhesive is presented with 5 optional widths of 15mm, 20mm, 30mm, 40mm, and 50mm, which can tolerate up to 280℃ and widely be used in the 3D printer projects, PCB soldering, and making insulation in transformer, motor, coil, capacitors, variable frequency power supply, and other electrical insulation.

Width:15mm / 20mm / 30mm / 40mm / 50mm (Optional
Length: 33m
Thickness: 0.05mm
Heat Resistance: 280℃
Tensile Strength: ≥ 42N / 25mm
Peel Force: ≥ 26N / 25mm
Holding Power: 48H
Material: Polyimide film (Kapton)
One-sided self-adhesive
Applied to protect components while soldering precise ICS

Package includes:
1 x Kapton Tape roll

Physical Parameters
Length 33m
Thickness 0.05mm
Material Polyimide film (Kapton)
