W2809 Digital Thermostat Module

The W2809 12V Panel-Mount Digital Thermostat is a precise and versatile tool for temperature control in various heating and cooling systems. This module allows users to manage temperatures accurately, making it ideal for applications such as heaters, air conditioners, and HVAC systems.

The W2809 Digital Thermostat Module comes with a high-resolution LCD display that shows temperature in both Celsius and Fahrenheit. It supports adjustable temperature settings from 0 to 99°C and includes a waterproof temperature sensor, making it suitable for use in a variety of environments.

The W2809 Panel-Mount Digital Thermostat provides reliable and efficient performance for precise temperature control. Separately, the W2809 Thermostat Module ensures easy and accurate management of heating and cooling devices.

Applications of the W2809 Digital Thermostat Module

1. Greenhouses
2. Incubators
3. Aquariums
4. Homes
5. Commercial refrigerators

Specifications of the 12V Digital Thermostat

1. Temperature Measurement Accuracy: 0.1°C
2. High Temperature Protection: 0 to 110°C
3. Measurement Input: Waterproof NTC Sensor (10K)
4. Temperature Range: -50 to 110°C
5. Operating Voltage: 12V DC
6. Static Current: Max 35mA
7. Output Power: Max 10A
8. Refresh Rate: 0.5 seconds
9. Control Voltage: Max 250V AC
