12-24V Solenoid Valve

A solenoid valve, also known as an electric control valve, is a device used to regulate the flow of liquids. By using electrical current to open and close the valve, it eliminates the need for additional mechanical parts, making installation simple and reliable. Because of its ease of operation, this solenoid valve is widely used in smart automation systems, modern irrigation setups, and other control applications.

The 12V electric valve operates with a power supply of 12 to 24 volts. Inside the upper section of the valve, a coil activates when electrical current passes through it, enabling the valve to open or close efficiently.

This 12V solenoid valve is also commonly used as a 12V water purifier solenoid valve, providing precise control of water flow in purification systems and other smart water management solutions.

Applications of the water Solenoid Valve

1. Modern irrigation
2. Smart automation

Specifications of the Plastic Solenoid Valve

1. Voltage: 12-24V
2. Water pressure: 0.2 ~ 0.8 MPa
3. Operating temperature: 0 ~ 60 °C
4. Motor dimensions: 25 × 25 mm
5. Water outlet diameter: 6.5 mm
6. Connector width: 6.3 mm
7. Water flow rate: 3 L/min
8. Power: 5W
